KOF-1/2-80-10-6-2
1/2" MNPT Static Mixer 6 elements, 5" long, PVDF Kynar
These Koflo threaded chemical mixers are available from 3/8" - 2" diameter and are constructed of schedule 80 unpigmented Kynar® PVDF . Complete with solid Kynar® mixing elements welded to the interior pipe wall, Koflo Kynar® PVDF static mixers offer a versatile, in-stock option for aggressive chemical mixing or other applications where enhanced chemical resistance and/or high temperature capability is a critical factor.
Typical Applications
- pH control.
- Aggressive chemical mixing.
- Thermal homogeneity.
Static mixers are versatile mixing devices that can be used in a wide range of industries and applications beyond those listed above.
Features
Housing: Schedule 80 Kynar® PVDF.
Elements: Koflo Blade™ Style Solid Kynar® PVDF.
End Connections: Machined Male NPT (Threaded Ends)
*Note that 3/8" Kynar® PVDF mixers use Koflo's helical design mixing elements
- Solid Kynar® PVDF design offers superior corrosion resistance.
- Lightweight and easy to install with male NPT threaded ends.
| Model Number | Pipe Dia. MNPT Ends | Number of Elements | Length | Weight | Max. Working Pressure (PSI @ 75°F) | Max. Working Temperature (°F) |
|---|---|---|---|---|---|---|
| 3/8-80-10-6H-2 | 3/8" | 6 | 4" | 0.10 lb | 400 | 240 |
| 3/8-80-10-12H-2 | 3/8" | 12 | 8" | 0.20 lb | 400 | 240 |
| 1/2-80-10-6-2 | 1/2" | 6 | 5" | 0.13 lb | 290 | 240 |
| 1/2-80-10-12-2 | 1/2" | 12 | 9" | 0.23 lb | 290 | 240 |
| 3/4-80-10-6-2 | 3/4" | 6 | 6" | 0.21 lb | 235 | 240 |
| 3/4-80-10-12-2 | 3/4" | 12 | 12" | 0.40 lb | 235 | 240 |
| 1-80-10-6-2 | 1" | 6 | 8" | 0.40 lb | 215 | 240 |
| 1-80-10-12-2 | 1" | 12 | 15" | 0.75 lb | 215 | 240 |
| 1.5-80-10-6-2 | 1.5" | 6 | 12" | 1.05 lb | 160 | 240 |
| 1.5-80-10-12-2 | 1.5" | 12 | 24" | 2.05 lb | 160 | 240 |
| 2-80-10-6-2 | 2" | 6 | 16" | 1.90 lb | 135 | 240 |
| 2-80-10-12-2 | 2" | 12 | 31" | 3.50 lb | 135 | 240 |
| Product Type: | Static Mixer |
| Brand: | Koflo |
| Material: | PVDF |
| Length: | 5" |
| Net Weight: | 0.13 lb |
